QEMU ARM Linux system using Buildroot and GPIO emulation

This post details building an ARM linux image via buildroot, emulation using QEMU and using it for emulated GPIO.

1. Build Linux Image

This was done using an Ubuntu 18.04.5 LTS host machine.

1. Buildroot

An ARM 64-bit embedded Linux system requires a file system, kernel image and user applications. Moreover, a cross compiler is needed to build one from scratch, and an emulator (like QEMU) is required if it will be tested on a non-ARM platform. Buildroot automates this process. It can do a lot more than what is described here and you should refer to its extensive documentation and training materials for details.

Download buildroot, generate an initial .config file and start menuconfig.

phwl@bream:~$ H=~/elec3607/
phwl@bream:~$ mkdir $H
phwl@bream:~$ cd $H
phwl@bream:~/elec3607$ git clone git://git.buildroot.net/buildroot
Cloning into 'buildroot'...
remote: Enumerating objects: 24805, done.
remote: Counting objects: 100% (24805/24805), done.
remote: Compressing objects: 100% (11902/11902), done.
remote: Total 401699 (delta 15432), reused 20763 (delta 12840), pack-reused 376894
Receiving objects: 100% (401699/401699), 87.06 MiB | 5.76 MiB/s, done.
Resolving deltas: 100% (279114/279114), done.
phwl@bream:~/elec3607$ cd buildroot/
phwl@bream:~/elec3607/buildroot$ make qemu_aarch64_virt_defconfig
mkdir -p /home/phwl/elec3607/buildroot/output/build/buildroot-config/lxdialog
PKG_CONFIG_PATH="" make CC="/usr/bin/gcc" HOSTCC="/usr/bin/gcc" \
    obj=/home/phwl/elec3607/buildroot/output/build/buildroot-config -C support/kconfig -f Makefile.br conf
/usr/bin/gcc -D_GNU_SOURCE -D_DEFAULT_SOURCE -DCURSES_LOC="<ncurses.h>" -DLOCALE  -I/home/phwl/elec3607/buildroot/output/build/buildroot-config -DCONFIG_=\"\"  -MM *.c > /home/phwl/elec3607/buildroot/output/build/buildroot-config/.depend 2>/dev/null || :
/usr/bin/gcc -D_GNU_SOURCE -D_DEFAULT_SOURCE -DCURSES_LOC="<ncurses.h>" -DLOCALE  -I/home/phwl/elec3607/buildroot/output/build/buildroot-config -DCONFIG_=\"\"   -c conf.c -o /home/phwl/elec3607/buildroot/output/build/buildroot-config/conf.o
/usr/bin/gcc -D_GNU_SOURCE -D_DEFAULT_SOURCE -DCURSES_LOC="<ncurses.h>" -DLOCALE  -I/home/phwl/elec3607/buildroot/output/build/buildroot-config -DCONFIG_=\"\"  -I. -c /home/phwl/elec3607/buildroot/output/build/buildroot-config/zconf.tab.c -o /home/phwl/elec3607/buildroot/output/build/buildroot-config/zconf.tab.o
/usr/bin/gcc -D_GNU_SOURCE -D_DEFAULT_SOURCE -DCURSES_LOC="<ncurses.h>" -DLOCALE  -I/home/phwl/elec3607/buildroot/output/build/buildroot-config -DCONFIG_=\"\"   /home/phwl/elec3607/buildroot/output/build/buildroot-config/conf.o /home/phwl/elec3607/buildroot/output/build/buildroot-config/zconf.tab.o  -o /home/phwl/elec3607/buildroot/output/build/buildroot-config/conf
rm /home/phwl/elec3607/buildroot/output/build/buildroot-config/zconf.tab.c
#
# configuration written to /home/phwl/elec3607/buildroot/.config
#
phwl@bream:~/elec3607/buildroot$ make menuconfig

Under menuconfig

 1. Select Kernel > Linux Kernel Tools > gpio
 1. Select Target Packages > Libraries > Hardware Handling > libgiod
 1. Select Target Packages > Libraries > Hardware Handling > libgiod install tools

Then save and type

make linux-menuconfig

After a while you will see the Linux kernel configuration menu.

 1. Select Device Drivers > GPIO Support > Memory mapped GPIO drivers > PrimeCell PL061 GPIO support

Build the image with

time make

After a while (30 minutes on my desktop machine), it should finish and then run QEMU using:

cd output/images
./start-qemu.sh

You should see the following output:

phwl@bream:~/elec3607/buildroot/output/images$ ./start-qemu.sh
Booting Linux on physical CPU 0x0000000000 [0x410fd034]
Linux version 5.4.58 (phwl@bream) (gcc version 9.3.0 (Buildroot 2020.11-607-gb4db6905a4)) #1 SMP Fri Jan 8 20:11:45 AEDT 2021
Machine model: linux,dummy-virt
efi: Getting EFI parameters from FDT:
efi: UEFI not found.
psci: probing for conduit method from DT.
psci: PSCIv0.2 detected in firmware.
psci: Using standard PSCI v0.2 function IDs
psci: Trusted OS migration not required
percpu: Embedded 21 pages/cpu s46936 r8192 d30888 u86016
Detected VIPT I-cache on CPU0
CPU features: detected: ARM erratum 845719
CPU features: detected: ARM erratum 843419
Built 1 zonelists, mobility grouping on.  Total pages: 32256
Kernel command line: rootwait root=/dev/vda console=ttyAMA0
Dentry cache hash table entries: 16384 (order: 5, 131072 bytes, linear)
Inode-cache hash table entries: 8192 (order: 4, 65536 bytes, linear)
mem auto-init: stack:off, heap alloc:off, heap free:off
Memory: 104460K/131072K available (6012K kernel code, 340K rwdata, 1416K rodata, 448K init, 326K bss, 26612K reserved, 0K cma-reserved)
SLUB: HWalign=64, Order=0-3, MinObjects=0, CPUs=1, Nodes=1
rcu: Hierarchical RCU implementation.
rcu: 	RCU restricting CPUs from NR_CPUS=256 to nr_cpu_ids=1.
rcu: RCU calculated value of scheduler-enlistment delay is 25 jiffies.
rcu: Adjusting geometry for rcu_fanout_leaf=16, nr_cpu_ids=1
NR_IRQS: 64, nr_irqs: 64, preallocated irqs: 0
GICv2m: range[mem 0x08020000-0x08020fff], SPI[80:143]
random: get_random_bytes called from start_kernel+0x2a8/0x420 with crng_init=0
arch_timer: cp15 timer(s) running at 62.50MHz (virt).
clocksource: arch_sys_counter: mask: 0xffffffffffffff max_cycles: 0x1cd42e208c, max_idle_ns: 881590405314 ns
sched_clock: 56 bits at 62MHz, resolution 16ns, wraps every 4398046511096ns
Console: colour dummy device 80x25
Calibrating delay loop (skipped), value calculated using timer frequency.. 125.00 BogoMIPS (lpj=250000)
pid_max: default: 32768 minimum: 301
Mount-cache hash table entries: 512 (order: 0, 4096 bytes, linear)
Mountpoint-cache hash table entries: 512 (order: 0, 4096 bytes, linear)
ASID allocator initialised with 32768 entries
rcu: Hierarchical SRCU implementation.
EFI services will not be available.
smp: Bringing up secondary CPUs ...
smp: Brought up 1 node, 1 CPU
SMP: Total of 1 processors activated.
CPU features: detected: 32-bit EL0 Support
CPU features: detected: CRC32 instructions
CPU: All CPU(s) started at EL1
alternatives: patching kernel code
devtmpfs: initialized
clocksource: jiffies: mask: 0xffffffff max_cycles: 0xffffffff, max_idle_ns: 7645041785100000 ns
futex hash table entries: 256 (order: 2, 16384 bytes, linear)
DMI not present or invalid.
NET: Registered protocol family 16
DMA: preallocated 256 KiB pool for atomic allocations
hw-breakpoint: found 6 breakpoint and 4 watchpoint registers.
Serial: AMBA PL011 UART driver
9000000.pl011: ttyAMA0 at MMIO 0x9000000 (irq = 39, base_baud = 0) is a PL011 rev1
printk: console [ttyAMA0] enabled
iommu: Default domain type: Translated
vgaarb: loaded
SCSI subsystem initialized
clocksource: Switched to clocksource arch_sys_counter
NET: Registered protocol family 2
tcp_listen_portaddr_hash hash table entries: 256 (order: 0, 4096 bytes, linear)
TCP established hash table entries: 1024 (order: 1, 8192 bytes, linear)
TCP bind hash table entries: 1024 (order: 2, 16384 bytes, linear)
TCP: Hash tables configured (established 1024 bind 1024)
UDP hash table entries: 256 (order: 1, 8192 bytes, linear)
UDP-Lite hash table entries: 256 (order: 1, 8192 bytes, linear)
NET: Registered protocol family 1
PCI: CLS 0 bytes, default 64
hw perfevents: enabled with armv8_pmuv3 PMU driver, 5 counters available
workingset: timestamp_bits=62 max_order=15 bucket_order=0
fuse: init (API version 7.31)
Block layer SCSI generic (bsg) driver version 0.4 loaded (major 251)
io scheduler mq-deadline registered
io scheduler kyber registered
pl061_gpio 9030000.pl061: PL061 GPIO chip registered
pci-host-generic 4010000000.pcie: host bridge /pcie@10000000 ranges:
pci-host-generic 4010000000.pcie:    IO 0x3eff0000..0x3effffff -> 0x00000000
pci-host-generic 4010000000.pcie:   MEM 0x10000000..0x3efeffff -> 0x10000000
pci-host-generic 4010000000.pcie:   MEM 0x8000000000..0xffffffffff -> 0x8000000000
pci-host-generic 4010000000.pcie: ECAM at [mem 0x4010000000-0x401fffffff] for [bus 00-ff]
pci-host-generic 4010000000.pcie: PCI host bridge to bus 0000:00
pci_bus 0000:00: root bus resource [bus 00-ff]
pci_bus 0000:00: root bus resource [io  0x0000-0xffff]
pci_bus 0000:00: root bus resource [mem 0x10000000-0x3efeffff]
pci_bus 0000:00: root bus resource [mem 0x8000000000-0xffffffffff]
pci 0000:00:00.0: [1b36:0008] type 00 class 0x060000
cacheinfo: Unable to detect cache hierarchy for CPU 0
virtio_blk virtio0: [vda] 122880 512-byte logical blocks (62.9 MB/60.0 MiB)
rtc-pl031 9010000.pl031: registered as rtc0
NET: Registered protocol family 10
Segment Routing with IPv6
sit: IPv6, IPv4 and MPLS over IPv4 tunneling driver
NET: Registered protocol family 17
NET: Registered protocol family 15
registered taskstats version 1
rtc-pl031 9010000.pl031: setting system clock to 2021-01-08T09:12:58 UTC (1610097178)
EXT4-fs (vda): mounted filesystem with ordered data mode. Opts: (null)
VFS: Mounted root (ext4 filesystem) readonly on device 254:0.
devtmpfs: mounted
Freeing unused kernel memory: 448K
Run /sbin/init as init process
EXT4-fs (vda): re-mounted. Opts: (null)
ext4 filesystem being remounted at / supports timestamps until 2038 (0x7fffffff)
Starting syslogd: OK
Starting klogd: OK
Running sysctl: OK
Saving random seed: random: dd: uninitialized urandom read (512 bytes read)
OK
Starting network: udhcpc: started, v1.32.0
random: mktemp: uninitialized urandom read (6 bytes read)
udhcpc: sending discover
udhcpc: sending select for 10.0.2.15
udhcpc: lease of 10.0.2.15 obtained, lease time 86400
deleting routers
random: mktemp: uninitialized urandom read (6 bytes read)
adding dns 10.0.2.3
OK

Welcome to Buildroot
buildroot login: IPv6: ADDRCONF(NETDEV_CHANGE): eth0: link becomes ready

Enter “root” as the user name and no password is required. You can exit QEMU with Ctrl-a x and get help with Ctrl-a h. The monitor is invoked with Ctrl-a c, and can provide information about the underlying hardware, e.g. the memory tree:

(qemu) info mtree
address-space: memory
  0000000000000000-ffffffffffffffff (prio 0, i/o): system
    0000000000000000-0000000003ffffff (prio 0, romd): virt.flash0
    0000000004000000-0000000007ffffff (prio 0, romd): virt.flash1
    0000000008000000-0000000008000fff (prio 0, i/o): gic_dist
    0000000008010000-0000000008011fff (prio 0, i/o): gic_cpu
    0000000008020000-0000000008020fff (prio 0, i/o): gicv2m
    0000000009000000-0000000009000fff (prio 0, i/o): pl011
    0000000009010000-0000000009010fff (prio 0, i/o): pl031
    0000000009020000-0000000009020007 (prio 0, i/o): fwcfg.data
    0000000009020008-0000000009020009 (prio 0, i/o): fwcfg.ctl
    0000000009020010-0000000009020017 (prio 0, i/o): fwcfg.dma
    0000000009030000-0000000009030fff (prio 0, i/o): pl061
    000000000a000000-000000000a0001ff (prio 0, i/o): virtio-mmio
    000000000a000200-000000000a0003ff (prio 0, i/o): virtio-mmio
    000000000a000400-000000000a0005ff (prio 0, i/o): virtio-mmio
    000000000a000600-000000000a0007ff (prio 0, i/o): virtio-mmio
    000000000a000800-000000000a0009ff (prio 0, i/o): virtio-mmio
    000000000a000a00-000000000a000bff (prio 0, i/o): virtio-mmio
    000000000a000c00-000000000a000dff (prio 0, i/o): virtio-mmio
    000000000a000e00-000000000a000fff (prio 0, i/o): virtio-mmio
    000000000a001000-000000000a0011ff (prio 0, i/o): virtio-mmio
    000000000a001200-000000000a0013ff (prio 0, i/o): virtio-mmio
    000000000a001400-000000000a0015ff (prio 0, i/o): virtio-mmio
    000000000a001600-000000000a0017ff (prio 0, i/o): virtio-mmio
    000000000a001800-000000000a0019ff (prio 0, i/o): virtio-mmio
    000000000a001a00-000000000a001bff (prio 0, i/o): virtio-mmio
    000000000a001c00-000000000a001dff (prio 0, i/o): virtio-mmio
    000000000a001e00-000000000a001fff (prio 0, i/o): virtio-mmio
    000000000a002000-000000000a0021ff (prio 0, i/o): virtio-mmio
    000000000a002200-000000000a0023ff (prio 0, i/o): virtio-mmio
    000000000a002400-000000000a0025ff (prio 0, i/o): virtio-mmio
    000000000a002600-000000000a0027ff (prio 0, i/o): virtio-mmio
    000000000a002800-000000000a0029ff (prio 0, i/o): virtio-mmio
    000000000a002a00-000000000a002bff (prio 0, i/o): virtio-mmio
    000000000a002c00-000000000a002dff (prio 0, i/o): virtio-mmio
    000000000a002e00-000000000a002fff (prio 0, i/o): virtio-mmio
    000000000a003000-000000000a0031ff (prio 0, i/o): virtio-mmio
    000000000a003200-000000000a0033ff (prio 0, i/o): virtio-mmio
    000000000a003400-000000000a0035ff (prio 0, i/o): virtio-mmio
    000000000a003600-000000000a0037ff (prio 0, i/o): virtio-mmio
    000000000a003800-000000000a0039ff (prio 0, i/o): virtio-mmio
    000000000a003a00-000000000a003bff (prio 0, i/o): virtio-mmio
    000000000a003c00-000000000a003dff (prio 0, i/o): virtio-mmio
    000000000a003e00-000000000a003fff (prio 0, i/o): virtio-mmio
    000000000c000000-000000000dffffff (prio 0, i/o): platform bus
    0000000010000000-000000003efeffff (prio 0, i/o): alias pcie-mmio @gpex_mmio 0000000010000000-000000003efeffff
    000000003eff0000-000000003effffff (prio 0, i/o): gpex_ioport
    0000000040000000-0000000047ffffff (prio 0, ram): mach-virt.ram
    0000004010000000-000000401fffffff (prio 0, i/o): alias pcie-ecam @pcie-mmcfg-mmio 0000000000000000-000000000fffffff
    0000008000000000-000000ffffffffff (prio 0, i/o): alias pcie-mmio-high @gpex_mmio 0000008000000000-000000ffffffffff

address-space: I/O
  0000000000000000-000000000000ffff (prio 0, i/o): io

address-space: cpu-memory-0
  0000000000000000-ffffffffffffffff (prio 0, i/o): system
    0000000000000000-0000000003ffffff (prio 0, romd): virt.flash0
    0000000004000000-0000000007ffffff (prio 0, romd): virt.flash1
    0000000008000000-0000000008000fff (prio 0, i/o): gic_dist
    0000000008010000-0000000008011fff (prio 0, i/o): gic_cpu
    0000000008020000-0000000008020fff (prio 0, i/o): gicv2m
    0000000009000000-0000000009000fff (prio 0, i/o): pl011
    0000000009010000-0000000009010fff (prio 0, i/o): pl031
    0000000009020000-0000000009020007 (prio 0, i/o): fwcfg.data
    0000000009020008-0000000009020009 (prio 0, i/o): fwcfg.ctl
    0000000009020010-0000000009020017 (prio 0, i/o): fwcfg.dma
    0000000009030000-0000000009030fff (prio 0, i/o): pl061
    000000000a000000-000000000a0001ff (prio 0, i/o): virtio-mmio
    000000000a000200-000000000a0003ff (prio 0, i/o): virtio-mmio
    000000000a000400-000000000a0005ff (prio 0, i/o): virtio-mmio
    000000000a000600-000000000a0007ff (prio 0, i/o): virtio-mmio
    000000000a000800-000000000a0009ff (prio 0, i/o): virtio-mmio
    000000000a000a00-000000000a000bff (prio 0, i/o): virtio-mmio
    000000000a000c00-000000000a000dff (prio 0, i/o): virtio-mmio
    000000000a000e00-000000000a000fff (prio 0, i/o): virtio-mmio
    000000000a001000-000000000a0011ff (prio 0, i/o): virtio-mmio
    000000000a001200-000000000a0013ff (prio 0, i/o): virtio-mmio
    000000000a001400-000000000a0015ff (prio 0, i/o): virtio-mmio
    000000000a001600-000000000a0017ff (prio 0, i/o): virtio-mmio
    000000000a001800-000000000a0019ff (prio 0, i/o): virtio-mmio
    000000000a001a00-000000000a001bff (prio 0, i/o): virtio-mmio
    000000000a001c00-000000000a001dff (prio 0, i/o): virtio-mmio
    000000000a001e00-000000000a001fff (prio 0, i/o): virtio-mmio
    000000000a002000-000000000a0021ff (prio 0, i/o): virtio-mmio
    000000000a002200-000000000a0023ff (prio 0, i/o): virtio-mmio
    000000000a002400-000000000a0025ff (prio 0, i/o): virtio-mmio
    000000000a002600-000000000a0027ff (prio 0, i/o): virtio-mmio
    000000000a002800-000000000a0029ff (prio 0, i/o): virtio-mmio
    000000000a002a00-000000000a002bff (prio 0, i/o): virtio-mmio
    000000000a002c00-000000000a002dff (prio 0, i/o): virtio-mmio
    000000000a002e00-000000000a002fff (prio 0, i/o): virtio-mmio
    000000000a003000-000000000a0031ff (prio 0, i/o): virtio-mmio
    000000000a003200-000000000a0033ff (prio 0, i/o): virtio-mmio
    000000000a003400-000000000a0035ff (prio 0, i/o): virtio-mmio
    000000000a003600-000000000a0037ff (prio 0, i/o): virtio-mmio
    000000000a003800-000000000a0039ff (prio 0, i/o): virtio-mmio
    000000000a003a00-000000000a003bff (prio 0, i/o): virtio-mmio
    000000000a003c00-000000000a003dff (prio 0, i/o): virtio-mmio
    000000000a003e00-000000000a003fff (prio 0, i/o): virtio-mmio
    000000000c000000-000000000dffffff (prio 0, i/o): platform bus
    0000000010000000-000000003efeffff (prio 0, i/o): alias pcie-mmio @gpex_mmio 0000000010000000-000000003efeffff
    000000003eff0000-000000003effffff (prio 0, i/o): gpex_ioport
    0000000040000000-0000000047ffffff (prio 0, ram): mach-virt.ram
    0000004010000000-000000401fffffff (prio 0, i/o): alias pcie-ecam @pcie-mmcfg-mmio 0000000000000000-000000000fffffff
    0000008000000000-000000ffffffffff (prio 0, i/o): alias pcie-mmio-high @gpex_mmio 0000008000000000-000000ffffffffff

address-space: gpex-root
  0000000000000000-ffffffffffffffff (prio 0, i/o): bus master container

memory-region: gpex_mmio
  0000000000000000-ffffffffffffffff (prio 0, i/o): gpex_mmio

memory-region: pcie-mmcfg-mmio
  0000000000000000-000000001fffffff (prio 0, i/o): pcie-mmcfg-mmio

memory-region: system
  0000000000000000-ffffffffffffffff (prio 0, i/o): system
    0000000000000000-0000000003ffffff (prio 0, romd): virt.flash0
    0000000004000000-0000000007ffffff (prio 0, romd): virt.flash1
    0000000008000000-0000000008000fff (prio 0, i/o): gic_dist
    0000000008010000-0000000008011fff (prio 0, i/o): gic_cpu
    0000000008020000-0000000008020fff (prio 0, i/o): gicv2m
    0000000009000000-0000000009000fff (prio 0, i/o): pl011
    0000000009010000-0000000009010fff (prio 0, i/o): pl031
    0000000009020000-0000000009020007 (prio 0, i/o): fwcfg.data
    0000000009020008-0000000009020009 (prio 0, i/o): fwcfg.ctl
    0000000009020010-0000000009020017 (prio 0, i/o): fwcfg.dma
    0000000009030000-0000000009030fff (prio 0, i/o): pl061
    000000000a000000-000000000a0001ff (prio 0, i/o): virtio-mmio
    000000000a000200-000000000a0003ff (prio 0, i/o): virtio-mmio
    000000000a000400-000000000a0005ff (prio 0, i/o): virtio-mmio
    000000000a000600-000000000a0007ff (prio 0, i/o): virtio-mmio
    000000000a000800-000000000a0009ff (prio 0, i/o): virtio-mmio
    000000000a000a00-000000000a000bff (prio 0, i/o): virtio-mmio
    000000000a000c00-000000000a000dff (prio 0, i/o): virtio-mmio
    000000000a000e00-000000000a000fff (prio 0, i/o): virtio-mmio
    000000000a001000-000000000a0011ff (prio 0, i/o): virtio-mmio
    000000000a001200-000000000a0013ff (prio 0, i/o): virtio-mmio
    000000000a001400-000000000a0015ff (prio 0, i/o): virtio-mmio
    000000000a001600-000000000a0017ff (prio 0, i/o): virtio-mmio
    000000000a001800-000000000a0019ff (prio 0, i/o): virtio-mmio
    000000000a001a00-000000000a001bff (prio 0, i/o): virtio-mmio
    000000000a001c00-000000000a001dff (prio 0, i/o): virtio-mmio
    000000000a001e00-000000000a001fff (prio 0, i/o): virtio-mmio
    000000000a002000-000000000a0021ff (prio 0, i/o): virtio-mmio
    000000000a002200-000000000a0023ff (prio 0, i/o): virtio-mmio
    000000000a002400-000000000a0025ff (prio 0, i/o): virtio-mmio
    000000000a002600-000000000a0027ff (prio 0, i/o): virtio-mmio
    000000000a002800-000000000a0029ff (prio 0, i/o): virtio-mmio
    000000000a002a00-000000000a002bff (prio 0, i/o): virtio-mmio
    000000000a002c00-000000000a002dff (prio 0, i/o): virtio-mmio
    000000000a002e00-000000000a002fff (prio 0, i/o): virtio-mmio
    000000000a003000-000000000a0031ff (prio 0, i/o): virtio-mmio
    000000000a003200-000000000a0033ff (prio 0, i/o): virtio-mmio
    000000000a003400-000000000a0035ff (prio 0, i/o): virtio-mmio
    000000000a003600-000000000a0037ff (prio 0, i/o): virtio-mmio
    000000000a003800-000000000a0039ff (prio 0, i/o): virtio-mmio
    000000000a003a00-000000000a003bff (prio 0, i/o): virtio-mmio
    000000000a003c00-000000000a003dff (prio 0, i/o): virtio-mmio
    000000000a003e00-000000000a003fff (prio 0, i/o): virtio-mmio
    000000000c000000-000000000dffffff (prio 0, i/o): platform bus
    0000000010000000-000000003efeffff (prio 0, i/o): alias pcie-mmio @gpex_mmio 0000000010000000-000000003efeffff
    000000003eff0000-000000003effffff (prio 0, i/o): gpex_ioport
    0000000040000000-0000000047ffffff (prio 0, ram): mach-virt.ram
    0000004010000000-000000401fffffff (prio 0, i/o): alias pcie-ecam @pcie-mmcfg-mmio 0000000000000000-000000000fffffff
    0000008000000000-000000ffffffffff (prio 0, i/o): alias pcie-mmio-high @gpex_mmio 0000008000000000-000000ffffffffff

(qemu)

You can also examine memory addresses e.g. to display a word at physical memory address 0x903000, and then display a byte:

(qemu) xp /x 0x09030000
0000000009030000: 0x00000000
(qemu) xp /xb 0x09030400
0000000009030400: 0xff

The ./start-qemu.sh script is shown below. It emulates a Cortex-A53 which is an ARMv8-A 64-bit processor.

#!/bin/sh
(
BINARIES_DIR="${0%/*}/"
cd ${BINARIES_DIR}

if [ "${1}" = "serial-only" ]; then
    EXTRA_ARGS='-nographic'
else
    EXTRA_ARGS=''
fi

export PATH="/home/phwl/elec3607/buildroot/output/host/bin:${PATH}"
exec qemu-system-aarch64 -M virt -cpu cortex-a53 -nographic -smp 1 -kernel Image
 -append "rootwait root=/dev/vda console=ttyAMA0" -netdev user,id=eth0 -device v
irtio-net-device,netdev=eth0 -drive file=rootfs.ext4,if=none,format=raw,id=hd0 -
device virtio-blk-device,drive=hd0  ${EXTRA_ARGS}
)

Refer to the QEMU documentation.

2. Installing packages

The usefulness of the Linux created is limited because very few packages were installed in the previous step. In the buildroot home directory, type

make menuconfig

select

  1. Target packages > Networking applications > openssh

and then type

make

This time the system will build much faster as only the openssh package needs to be downloaded, compiled and placed in the system image. Inside this new QEMU environment, you can

ssh 10.0.2.2

to connect to the host.

3. User Application: Hello QEMU

Create the following C program in some directory outside of the buildroot ones (I chose $H/labs/lab1 so the file is $H/labs/lab1/hello.c).

1
2
3
4
5
6
#include <stdio.h>

main()
{
	printf("Hello QEMU\n");
}

To compile it, we must remember to use a cross compiler as the target is not the host machine but rather the guest ARM machine. Fortunately, can use the cross compiler that buildroot created:

$H/buildroot/output/host/bin/aarch64-linux-gcc -o hello hello.c

Start up the guest Linux with QEMU,copy the file from the host and execute

phwl@bream:~/elec3607/buildroot/output/images$ cd $H/buildroot/output/images
phwl@bream:~/elec3607/buildroot/output/images$ ./start-qemu.sh
Booting Linux on physical CPU 0x0000000000 [0x410fd034]
...
Starting sshd: OK

Welcome to Buildroot
buildroot login: root
# scp phwl@10.0.2.2:elec3607/labs/lab1/hello .
phwl@10.0.2.2's password:
hello                                         100% 8680   852.3KB/s   00:00
# ./hello
Hello QEMU
#

2. GPIO

1. Linux libgpiod Library Command Line Tools on QEMU

Refer to BeagleBone Green gpio for an introduction to libgpiod.

Here we use the libgpiod tools to determine there is one gpiochip (gpiochip0) and that they are initially all set as inputs. We can also see that while gpio lines can have names, all of the ones on this machine are unnamed.

phwl@bream:~/elec3607/buildroot/output/images$ H=~/elec3607
phwl@bream:~/elec3607/buildroot/output/images$ cd $H/buildroot/output/images
phwl@bream:~/elec3607/buildroot/output/images$ ./start-qemu.sh
Booting Linux on physical CPU 0x0000000000 [0x410fd034]
... sh
Welcome to Buildroot
buildroot login: root
# gpiodetect
gpiochip0 [9030000.pl061] (8 lines)
# gpioinfo
gpiochip0 - 8 lines:
	line   0:      unnamed       unused   input  active-high
	line   1:      unnamed       unused   input  active-high
	line   2:      unnamed       unused   input  active-high
	line   3:      unnamed       unused   input  active-high
	line   4:      unnamed       unused   input  active-high
	line   5:      unnamed       unused   input  active-high
	line   6:      unnamed       unused   input  active-high
	line   7:      unnamed       unused   input  active-high
#

Here is a link to a tutorial explaining the changes https://microhobby.com.br/blog/2020/02/02/new-linux-kernel-5-5-new-interfaces-in-gpiolib/.

2.1 Using gpiod

Using the gpiod library, the following program will change the state of pin 3 on gpiochip0 ten times.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
/*
**    blink.c -    blink gpiochip0 line 3 with delay given by either
**                 the command line or the default (NSPERIOD)
*/

#include <stdio.h>
#include <unistd.h>
#include <gpiod.h>

#define NSPERIOD    200000000ULL    /* output period in ns */

int
main(int argc, char *argv[])
{
    struct gpiod_chip *output_chip;
    struct gpiod_line *output_line;
    struct timespec delay = {0, NSPERIOD};
    struct timespec rem;
    int line_value;

    if (argc == 2)
        delay.tv_nsec = atoll(argv[1]);

    /* open /dev/gpiochip0 */
    output_chip = gpiod_chip_open_by_number(0);

    /* work on pin 3 */
    output_line = gpiod_chip_get_line(output_chip, 3);

    /* config as output and set a description */
    gpiod_line_request_output(output_line, "blink",
                  GPIOD_LINE_ACTIVE_STATE_HIGH);

    for (int i = 0; i < 10; i++)
    {
        line_value = !line_value;
        gpiod_line_set_value(output_line, line_value);
            nanosleep(&delay, &rem);
    }

    return 0;
}

If the C program is written to ~/src/teaching/labs/lab2/blink.c, it can be compiled using:

phwl@bream:~/elec3607/labs/lab2$ H=~/src/teaching/
phwl@bream:~/elec3607/labs/lab2$ $H/buildroot/output/host/bin/aarch64-buildroot-linux-uclibc-gcc -o blink blink.c -lgpiod

In QEMU you can copy the file from the host to the guest and execute:

# scp phwl@10.0.2.2:src/teaching/labs/lab2/gpio .
phwl@10.0.2.2's password:
# ./gpio
#

2.2 Displaying GPIO_DATA

Nothing appears to happen as there is no output in QEMU. Normally in an embedded system (as the name of the program suggests), we would have the GPIO line connected to an LED, which would blink according to the program.

The GPIO peripheral used in the qemu_aarch64_virt machine is described in the ARM PrimeCell General Purpose Input/Output (PL061) Technical Reference Manual (which we will call the datasheet). During boot up, the message

pl061_gpio 9030000.pl061: PL061 GPIO chip registered

or using info mtree in the QEMU monitor, you get

0000000009030000-0000000009030fff (prio 0, i/o): pl061

shows that the start address (GPIOBASE in the datasheet) is 0x9030000. The address of GPIODATA is 0x9030000-0x9030ff and GPIODIR is 0x9030400.

We can use the following program to interrogate the state of the GPIODATA register in the PL061 and print its value when it changes.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
/*
**    pl061-change.c     - display changes to the GPIO_GPIODATA state
*/

#include <stdio.h>
#include <sys/mman.h>
#include <sys/types.h>
#include <sys/stat.h>
#include <fcntl.h>
#include <time.h>

#define GPIO0_START_ADDR 0x09030000
#define GPIO0_END_ADDR   0x09030fff
#define GPIO0_SIZE (GPIO0_END_ADDR - GPIO0_START_ADDR)

#define GPIO_GPIODATA    0

/* high resolution time stamp */
double
gethrtime()
{
    int    r;
    int64_t    ts;
    struct timespec t;

    /* read the time stamp */
    r = clock_gettime(CLOCK_MONOTONIC, &t);
    ts = (int64_t)(t.tv_sec) * (int64_t)1000000000 + (int64_t)(t.tv_nsec);
    return ts / 1.0e9;
}

int
main()
{
    volatile void *gpio_addr;
    volatile unsigned char *gpio_gpiodata_addr;
    unsigned char        c, oldc;

    int fd = open("/dev/mem", O_RDWR);
    gpio_addr = mmap(0, GPIO0_SIZE, PROT_READ | PROT_WRITE,
            MAP_SHARED, fd, GPIO0_START_ADDR);

    gpio_gpiodata_addr   = gpio_addr + GPIO_GPIODATA + 0xff;


    oldc = c = *gpio_gpiodata_addr;

    for (;;)
    {
        c = *gpio_gpiodata_addr;
        if (c != oldc)
        {
            oldc = c;
            printf("GPIODATA=%x (t=%fs)\n", c, gethrtime());
        }
    }
}

After copying it to the guest, it can be used to verify blink as follows:

# ./pl061-change &
# ./blink
GPIODATA=8 (t=46.833710s)
GPIODATA=0 (t=47.033845s)
GPIODATA=8 (t=47.233977s)
GPIODATA=0 (t=47.434119s)
GPIODATA=8 (t=47.634252s)
GPIODATA=0 (t=47.834385s)
GPIODATA=8 (t=48.034518s)
GPIODATA=0 (t=48.234652s)
GPIODATA=8 (t=48.434785s)
GPIODATA=0 (t=48.634919s)

The time on the output shows that the period of the GPIO output change is roughly 0.2s which is close to the value of NSPERIOD (the desired delay in nanoseconds) specified in blink.c.

3. libgpiod Application Programmers’ Interface Programming

Is it possible to display the state of the GPIO while simultaneously writing to it? The first shell command sets gpiochip0 line 1, and stays in the background (the -b option) for 10 seconds (-mtime -s10) before ending. You can’t read the line with gpioget until the gpioset program ends.

# gpioset -b -mtime -s10 gpiochip0 1=1
# gpioget gpiochip0 1
gpioget: error reading GPIO values: Device or resource busy
#

Normally, we use the GPIO pins to control something and don’t need to read what we wrote. But is it possible to do so in QEMU? The solution turned out more complicated than I would have liked.

The first thing is that we want to do the read and write in parallel, not as two separate processes. There are many ways to do this but multithreading (using POSIX threads) is one solution. The second problem is that the writer must release the line so that the reader can access it or you get the same “Device or resource busy” error.

The code below implements these ideas. The gpio_reader() function checks when a pin changes and prints the new state. This gpiod_line_event_wait() function will return with a value > 0 if an event has occurred and we print the pin state and time. Otherwise, it either encountered an error or timed out. The gpio_writer() function toggles the output after a fixed delay, specified in the delay structure. A mutual exclusion (via the mutexline variable) is used to ensure that only the reader or writer has access to the line at any time. This restricts the line to either be an output (via gpiod_line_request_output()) or an event (via gpiod_line_request_both_edges_events()) at any time, not both.

These two threads run in parallel and when they get the line, will perform their task, after which they sleep (via nanosleep()). The gpio_reader() function executes about 100x faster than the writer.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
/*
**    Blinky under QEMU and libgpiod
*/

#include <stdio.h>
#include <stdlib.h>
#include <pthread.h>
#include <assert.h>
#include <gpiod.h>
#include <time.h>

#define CONSUMER "gpiod-lab"        /* this identifies the consumer */
#define NUM_THREADS 2               /* we have one writer and one reader */
#define NSPERIOD    200000000ULL    /* output period in ns */

pthread_mutex_t mutexline;          /* only reader or writer can access line */

/* create thread argument struct for thr_func() */
typedef struct _thread_data_t
{
    int tid;
    struct gpiod_line *gpioline;
} thread_data_t;

/* high resolution time stamp */
double
gethrtime()
{
    int    r;
    int64_t    ts;
    struct timespec t;

    /* read the time stamp */
    r = clock_gettime(CLOCK_MONOTONIC, &t);
    ts = (int64_t)(t.tv_sec) * (int64_t)1000000000 + (int64_t)(t.tv_nsec);
    return ts / 1.0e9;
}

/*
**    Display edges
*/
void
gpio_reader(struct gpiod_line *line)
{
    struct timespec timeout = { 0, NSPERIOD / 100ULL };
    struct timespec shortdelay = { 0, NSPERIOD / 100ULL };
    struct timespec rem;
    int    r, v;
    int    event = 0;

    for (;;)
    {
        /* get exclusive access to the line */
        pthread_mutex_lock (&mutexline);

        /* get line */
        if (r = gpiod_line_request_both_edges_events(line, CONSUMER))
            goto release;

        /* wait for an event */
        r = gpiod_line_event_wait(line, &timeout);
        if (r > 0)    /* success */
        {
            /* read the gpio pin value */
            v = gpiod_line_get_value(line);
            printf("Event %d: Pin=%d at t=%fs\n", ++event, v, gethrtime());
        }

        /* release the line */
    release:
        gpiod_line_release(line);
        pthread_mutex_unlock (&mutexline);
        nanosleep(&shortdelay, &rem);
    }
}

/*
**    Blink a number of times
*/
void
gpio_writer(struct gpiod_line *line)
{
    struct timespec delay = { 0, NSPERIOD / 2 };
    struct timespec rem;
    int    v = 0;
    int    r;

    for (int i = 0; i < 10; i++)
    {
        /* get exclusive access to the line */
        pthread_mutex_lock (&mutexline);
        /* config as output and set a description */
        if (r = gpiod_line_request_output(line, CONSUMER, v))
            goto release;

        /* toggle output */
        v = !v;
        gpiod_line_set_value(line, v);

        /* release line */
    release:
        gpiod_line_release(line);
        pthread_mutex_unlock (&mutexline);
        nanosleep(&delay, &rem);
    }
}

/*
**    Create pthreads - the thread created will either be a reader or writer
*/
void *thr_func(void *arg) {
    thread_data_t *data = (thread_data_t *)arg;

    switch(data->tid)
    {
        case 0: /* writer */
            gpio_writer(data->gpioline);
            break;
        default: /* reader */
            gpio_reader(data->gpioline);
            break;
    }

    pthread_exit(NULL);
}

int
main(int argc, char **argv)
{
    pthread_t thr[NUM_THREADS];
    pthread_attr_t attr;
    int i, r;
    /* create a thread_data_t argument array */
    thread_data_t thr_data[NUM_THREADS];

    /* gpio structures */
    struct gpiod_chip *output_chip;
    struct gpiod_line *output_line;

    /* open /dev/gpiochip0 */
    output_chip = gpiod_chip_open_by_number(0);

    /* work on pin 3 */
    output_line = gpiod_chip_get_line(output_chip, 3);

    /* create threads */
    pthread_mutex_init(&mutexline, NULL);
    for (i = 0; i < NUM_THREADS; ++i)
    {
        thr_data[i].tid = i;
        thr_data[i].gpioline = output_line;
        assert(pthread_create(&thr[i], NULL, thr_func, &thr_data[i]) == 0);
    }
    /* block until thread 0 completes */
    pthread_join(thr[0], NULL);
    fflush(stdout);

    return EXIT_SUCCESS;
}

If the C program is written to ~/src/teaching/labs/lab2/gpio.c, it can be compiled using:

phwl@bream:~/elec3607/labs/lab2$ H=~/src/teaching/
phwl@bream:~/elec3607/labs/lab2$ $H/buildroot/output/host/bin/aarch64-buildroot-linux-uclibc-gcc -o gpio gpio.c -lgpiod -lpthread

When executed under QEMU (it needs to first be transferred to the guest via ssh), you will see:

# scp phwl@10.0.2.2:src/teaching/labs/lab2/gpio .
phwl@10.0.2.2's password:
# ./gpio
Event 1: Pin=1 at t=19925.878483s
Event 2: Pin=0 at t=19925.978926s
Event 3: Pin=1 at t=19926.077777s
Event 4: Pin=0 at t=19926.179461s
Event 5: Pin=1 at t=19926.277994s
Event 6: Pin=0 at t=19926.381006s
Event 7: Pin=1 at t=19926.479734s
Event 8: Pin=0 at t=19926.582780s
Event 9: Pin=1 at t=19926.681464s
Event 10: Pin=0 at t=19926.784994s
